When standard-output kits aren't bright enough, this one delivers up to 6,670 lumens for taller ceilings and demanding spaces while delivering a significant cost reduction compared to HO fluorescent tubes.
Up to 31% more output than the 35W kit, built for 2x4 and 1x4 fluorescent troffers in medium-to-high ceilings.
No drilling or tools required: magnetic install, 5 color temps, quick-connect plug.
15 wattage/color temperature combinations let you set the best for your space—and change it down the road if your use of space changes.
When standard-output kits aren't bright enough, this one delivers up to 6,670 lumens for taller ceilings and demanding spaces while delivering a significant cost reduction compared to HO fluorescent tubes.
Up to 31% more output than the 35W kit, built for 2x4 and 1x4 fluorescent troffers in medium-to-high ceilings.
No drilling or tools required: magnetic install, 5 color temps, quick-connect plug.
15 wattage/color temperature combinations let you set the best for your space—and change it down the road if your use of space changes.
Wire driver into your mains, attach kits to metal surface, plug kits into driver
Working Environment
Indoor
Light Type
Retrofits and Conversion Kits
LED Type
LED 2835
Input Voltage
120-277VAC / 120-347VAC, 50/60 Hz
Power Factor
>0.90
Surge Protection
1kV line-line, 2kV line-earth
Housing Material
Aluminum
Certification
DLC 5.1, ETL
Warranty
5 Years
Additional Specifications
Each kit contains two 4ft magnetic linear LED retrofit strips + an external magnetic-mount LED driver capable of 0-10V dimming. Frosted lens covers optional.
More Light, Same Easy Install for Spaces That Need It
The standard 35W kit is great for typical office and corridor installations. But if you're working with taller ceilings, wide-open floor plans, or spaces where strong, even illumination is non-negotiable, such as warehouses, gyms, and large retail floors, this is the kit to reach for.
High-Output Wattage Options: Choose 30W, 38W, or 46W on the driver. At 46W, this kit produces up to 6,670 lumens at up to 145 lm/W, significantly more than the 35W kit without requiring a different fixture.
Built for Medium-to-High Ceilings: Higher mounting heights demand more lumens to achieve adequate floor-level illumination. This kit delivers what lower-output options can't.
Easy Install: Magnetic strips and driver snap in, and the quick-connect plug cuts wiring to a minimum. Faster retrofit option than LED tubes & less waste than a full fixture replacement.
5 Color Temperatures: Full range from 2700K (warm white) to 5000K (daylight), selectable right on the driver at install, eliminates risk of guessing which color temperature to order: simply select the one that looks best in your space by seeing it in your space.
Rebate-Eligible: DLC Premium certification and ETL listing mean this kit qualifies for utility rebates in most areas.
A strong choice for offices with 12ft+ ceilings, retail showrooms, gyms, cafeterias, and any space where standard-output kits come up short.
Each kit includes: Two 4ft LED strips + one 0-10V dimmable LED driver.
Optional: Screw-in frosted lenses available as an accessory.
Layout & Planning
Request a Custom Layout
Complex or unique space? Get a custom layout plan from our lighting experts.
Save More with Rebates
Check available incentives in your area to reduce your upfront cost.
Excellent and easy to use kit
We have a custom light fixture in the home we just purchased that was using fluorescent tubes. I was looking for an option to modernize it while keeping the design. This LED retrofit kit was perfect for it. I was able to remove the old "guts" of the fixture, including the tubes, then simply wire up the new driver and the four LED strips and stick them to the metal housing. Super easy and now we can adjust color temperature and light level. And no more flickering or buzzing from aging fluorescent drivers.
Great Retrofit Replacement with built-in options
I like that you added switches to select the power as well as the temperature! Great improvement from earlier versions I purchased that had just a default setting.
Easy to install.
The plug and play system was very simple to install and the lights work great. The only issue I had was trying to install a dimmer switch. There were no wiring diagrams or instructions for this application.
Great product, easy installation....
Great product, easy installation. The magnetic strips make for a fast, secure installation. Great relief to not have to mess around with replacement bulbs or ballasts. Will definitely use these again in the future.
Six stars out of five--
The easiest conversion from florescent fixtures ever. Extremely versatile with the ability to choose brightness and color tone these two went into my model railroad room. They do a great job of rendering true color in the scenery and rolling stock. I will be converting the remaining three shortly.
Could Not Have Been Easier
I’m not usually one to comment or review items, but I wanted to let you know that I was incredibly impressed with the retrofit kit I purchased. It could not have been easier to install, and works perfectly.
While I cannot speak to the longevity of the kit at this point, if it holds up well, I could not ask for more!
Great Product
This 2x2 troffer retro kit is a great product. Of all the choices that pop up on the internet, I made the right one. The components being magnetic and the cabling a usable length it allows for a neat install. Reusing the ballast cover and lampholder bracket to hide the driver and wires, eliminates any shadows to show through the diffuser. A local hardware store still selling U-tubes at $17.00 each makes your product a no brainer at $34.00.
Very Easy to install....
Very Easy to install. Just take out everything other than the power feed in the existing fixture and connect this and plug it in. One issue though is there appear to be 2 leads for dimming possibly, but no instructions on how that is supposed to work? So i would give 4.5 stars due to the lack of communication, but I didn't need the dimming.
Such easy install
100% one of the finest led kits I have ever installed. Easy installation, bright, functional , quality materials, the magnetic strips on the leds and driver work fantastic. Buy it and thank me later.
Great service and perfect for my application
Good service, received my lights way before I had expected them. Easy install. Perfect for my application. My representative was great to work with.
I was very impressed...
I was very impressed by the ease of the installation, the order came quick and the lights look great. Washington fitters local 602 should be ordering around 50 to be installed
Very easy to install if you know a little bit about electrical work. However directions should be clearer with better pictures and more verbiage. Specifically regarding ground and dimmer wires.
Ease of installing.
Easy Install, Great Results
After modifying my existing fixtures to fit their space properly was I able to install the retrofit kit. Very attractive and provides great light. Note: One strip is emitting blue instead of the yellowish orange light of the other five.
Store owner replied:
Thank you for your positive review! We appreciate you letting us know about the one strip that’s putting out blue light — our team will be in touch soon to get that resolved.
Great product and Connor was a great resource!
Connor was an excellent resource in providing information as well as securing the PPL rebate and arranging the pick-up. We were so pleased with the product (our original order of 25 retrofit kits) that we ordered an additional 75 kits to change out much of the remaining fluorescent lights.
